IP125.8

IP SERIES

Customizable installation amplifier with control SW for commercial install. The IP series feature full matrix DSP, easy connection via WiFi and include regulatory certifications.

Specifications

Features

Downloads

Contact Pascal Sales

IP125.8 Specifications

Power Ratings (1% THD @ 120VAC and 230VAC) 4 Ω 8 Ω 70 V 100 V

Single channel 250 W 250 W 250 W 250 W

All channels 125 W 125 W 125 W 125 W

Dimensions, H x W x D

44.5 x 440 x 320 mm (1.75 x 17.32 x 11.50 in)

Weight

3.6 kg (7.8 Ibs)

Output Circuitry

UMAC™ Class D - full bandwidth PWM modulator with ultra-low distortion

Output Voltage

45 Vrms (Lo-Z) - 70/100V (Hi-Z)

Signal To Noise-Ratio

> 106 dB (A-weighted, 20 Hz – 20 kHz, 8 Ω load)

THD+N (typical)

< 0.05% (20 Hz – 20 kHz, 8 Ω load, 3 dB below rated power)

Frequency Response

20 Hz – 20 kHz (+/- 0.5 dB, 8 Ω load, 3 dB below rated power)

Protection Circuits

Short circuit -, DC -, Undervoltage -, Temperature- and Overload protection

Power Supply

UREC™ universal mains switch mode power supply with Power Factor Correction (PFC) and standby converter

Operating temperature

0 – 40 C

Operation Voltage

Universal Mains, 100V - 240V, 50Hz - 60Hz

Standby Consumption

< 0.5 W

Accessories

Rack Mount included – Pre-mounted on Amp

Power Ratings

1 % THD @ 120 Vac and 230 Vac

*100V line mode operates @ -1dB (≈ 90V)
** may only powershare across:
IP60.8: Ch 1/2/3/4 and Ch 5/6/7/8
IP1258. Ch 1/2, Ch 3/4, Ch 5/6, Ch 7/8

IP125.8 Features

Intuitive Control SW

The IP series are configured by intuitive Control SW optimized for commercial and residential install. The
interface provides simple and user friendly configuration. Please contact your Pascal sales person for a review of the interface.

High Power Density & Flexibility

IP series offers market leading power density with up to 4 x 125 W constant voltage channels from a 1RU half rack format. Additionally, the series can also power share up to 250W per channel offering maximum flexibility for the installer.

Highly Customizable

For unique ID front panel mechanics and lexan foil can be customized. The series also features Control SW, allowing for custom functionality and presets to match complementary manufacturers products. For high volume projects, full API control can be offered.

Turnkey Solution & Certification

IP series amplifiers are offered as a complete box build including cable, manuals and packaging ready to ship. Rack mounting accessories are also available. Furthermore, it comes with Safety and EMC certifications.

Market Proven Reliability

IP series amplifiers are based on Pascal ’s market proven amplifier designs, which are recognized for high reliability from more than a decade in the pro audio industry.

Universal Mains & PFC

Pascal’s UREC™ PFC (Power Factor Correction) power supply technology enables universal AC mains operation, eliminating the need for local market specific power regulation products and susceptibility to related reliability issues. The power supply delivers consistent, regulated power worldwide.

Download

File name Document size Version Last updated

Data sheet PDF (631.75 KB) 1.0 21-10-2021
